This product is a highly integrated wireless monitoring terminal for industrial environments, integrating the measurement functions of six key parameters: magnetic field, wind speed, temperature, oxygen concentration, Bluetooth function detection, and weight. It adopts LoRa wireless communication technology to realize remote transmission and centralized monitoring of data. It is particularly suitable for complex industrial scenarios requiring multi-parameter collaborative monitoring, such as performance testing of refrigerators and air conditioning systems, material weighing management, etc., providing users with a comprehensive environmental data collection solution.
+86 0532-80918305
| Magnetic Field Measurement | Measurement range | 2mT~3000mT（auto-ranging） |
| Accuracy class | Class 1/Class 2 optional | |
| Operating mode | AC/DC one-key switching | |
| Display units | G, mT, A/m optional | |
| Special functions |
N/S polarity display, relative measurement, maximum value hold, over-limit alarm |
|
| Wind Speed Measurement | Measurement range | 0~20m/s |
| Accuracy | ±0.02%F.S.（0~1m/s） | |
| Resolution | 0.01m/s | |
| Temperature Measurement | Measurement range | -40℃~+85℃ |
| Accuracy | ±0.5℃（-10℃~+85℃） | |
| Oxygen Concentration | Measurement range | 0~100%O₂ |
| Accuracy | ±0.5%（within 0~30% range） | |
| Response time | Approximately 15 seconds | |
| Weight Measurement | Maximum range | 5kg（customizable） |
| Accuracy | 0.1g(optional) | |
| Battery | 3200mAh | |
| System Parameters | Communication method | LoRa wireless |
| Power supply | Lithium battery/external DC power supply |
