Oxygen Concentration Module
Product Introduction

This product is an industrial-grade oxygen concentration detector integrated with LoRa wireless communication functionality. Adopting the galvanic cell diffusion principle, it can continuously and stably monitor the oxygen concentration in the environment and remotely transmit data to the monitoring center via the LoRa network. Equipped with local digital display, automatic calibration and other functions, the product is particularly suitable for various industrial sites and warehousing environments that require wireless remote monitoring of oxygen concentration, enabling early warning and real-time management of potential hazards.

+86 0532-80918305

Product Features
Accurate oxygen detection
Adopting the galvanic cell principle, specifically designed for oxygen detection, it is accurate and reliable.
Wireless communication
Integrated with LoRa wireless communication, it enables remote data monitoring and features flexible deployment.
Automatic calibration and easy operation
It is equipped with dual safety guarantees: local alarm and remote status monitoring.
Long-lasting battery life
Ultra-low power consumption design combined with LoRa technology ensures long-lasting battery life.
Equipment parameters
Detection Principle  Galvanic cell diffusion type
Detected Gas Oxygen (O₂)
Display Mode 3.5-digit digital display
Measurement Range 0 ~ 100% O₂
Measurement Accuracy ±0.5% O₂ (within the range of 0% ~ 30% O₂)
Response Speed Approximately 15 seconds (to reach 90% of the response value)
Remote Alarm Method LoRa
Communication Mode LoRa wireless communication
Calibration Method One-key automatic calibration using clean air
Operation Modes Simple mode, Free mode


Common test substances
