Temperature detection - Digital temperature sensor
Product Introduction

This product is a high-reliability temperature acquisition cable specially designed for industrial environments. It integrates a high-performance digital temperature sensor, connected via a high-strength tensile cable, with a standard industrial aviation connector as the terminal output. The copper cap protection design of the sensor ensures measurement accuracy and durability for long-term use. The product can stably and accurately transmit temperature data to acquisition modules or control systems through the aviation connector, making it an ideal front-end component for building reliable distributed temperature measurement networks.

+86 0532-80918305

Product Features
High-precision measurement
It has a built-in high-precision digital temperature-sensing chip, with a temperature measurement accuracy of up to ±1°C and a maximum resolution of 0.0625°C.
Durable and robust
The sensor end is protected by a fully sealed copper cap, featuring corrosion resistance and impact resistance; the cable is made of high-strength tensile material, suitable for complex industrial environments.
Rapid deployment
The terminal is equipped with an industrial aviation connector, featuring reverse connection protection, supporting quick plugging/unplugging and reliable connection, which simplifies on-site installation.
Wide temperature range operation
It features a wide temperature measurement range of -55°C to +125°C, meeting the requirements of most harsh scenarios.
Anti-interference design
Digital signal transmission with strong anti-interference capability.
Equipment parameters


Temperature measurement range -55°C ~ +125°C
Temperature measurement accuracy ±0.5°C (within the range of -10°C ~ +85°C)
Sensor protection Fully sealed copper protective cap
Cable type High-strength tensile and wear-resistant cable
Output interface

Industrial aviation connector (number of pins customizable, e.g.,

 3-pin or 4-pin)

Power supply mode 5V DC power supplied via aviation connector


Common test substances
